VIGI NVR4032H
VIGI 32 Channel Network Video Recorder.
No hard drive included.
Specifications
| Included Storage | No hard drive included; compatible surveillance HDD sold separately. |
|---|---|
| IP Video Input | 32-Channel |
| Incoming Bandwidth | 320 Mbps |
| Outgoing Bandwidth | 320 Mbps |
| HDMI Output Resolution | 1 Channel, Resolution: 3840×2160/30Hz,1920×1080/60Hz, 1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| VGA Output Resolution | 1 Channel, Resolution: 1920×1080/60Hz,1680×1050/60Hz, 1440×900/60Hz, 1280×1024/60Hz, 1280×720/60Hz, 1024×768/60Hz |
| Video Compression | H.265+/H.265/ H.264+/H.264 |
| Capability | 4-ch@8MP (25fps), 6-ch@5MP (25fps), 8-ch@4MP (25fps), 10-ch@3MP (25fps), 16-ch@1080P (25fps) |
| Network Interface | 2, RJ-45 10/100/1000 Mbps Self-Adaptive Ethernet Interface |
| Power | 1× AC Jack |
| SATA | 4 SATA Interfaces |
| Capacity | Up to 16 TB Capacity for Each HDD* |
| Working Temperature | • NVR: -10–55 °C• Power Adapter: 0–40 °C |
| Dimensions( W X D X H ) | 440 × 330 × 44 mm |
| Net Weight | 4.0 Kg§ |
| Power Supply | 100-240 VAC, 50 to 60HZ, 1.5A |
| Max. Power Consumption | • 5 W (Without Disk)• 48 W (With Disk) |
